Light 40

A unique design makes this serie ideal for small, light & sound, lifting requirements:

• Loading capacity 40 kg.
• Maximum height 2,8m



Simple use and total security

Goliath studio light 40 is powered by a rack and pinion drive in replacement of the usual winch cable pulley systems. The rack and pinion drives system provides a smooth and regular lifting operation of your lights and electronic equipment and reduces (up to 10 times versus cable systems) the movement at the top when fully erected. Coupled to a permanent brake system (patented), that secure the load in all circumpstances. There is no need to stop lifting to position safety pins, This is a real improvement in efficiency and security!




High quality standard

The light 40 100% aluminum built, benefits from a high quality design and manufacturing.




Stability

The lifters comes with a foldable tripod foot arangment, exceptionnally stable. The foot end is fitted with a solid grip feature.




Flexible fittings

The lifters are supplied with a 35mm end, convenient for most accessoiries or speaker hole.

• Min. height : 5.6ft/1,70m
• Stand diameter : 4ft/1,20m
• Unit weight : 9.3 Kg
• Materials : 100% aluminium
• Stands : Removable system 3-feet with stability link
• Number of modules : 2 telescopic modules
• Bubble level : No
• Removable handle : Yes
• Adjustment scale : No
• Transport cover : not included
• Transport wheels : No
• Output/Adaptor : Output 35mm male
• Maximum load : 88.2lbs/40kg

This user manual has been designed to allow you to use your Goliath Studio Lifter R Series in the best conditions of safety and efficiency.

You can download the manual user below .
Also, you can use your own accessories and structures. For more details, see below.
